MB Connect Line mbNET Series User Manual

Page 14 of 237
Version: 5.1.6 – June 4
th
, 2019
Datasheet
General data
Voltage V (DC)
10 – 30V DC (external Power Supply or other SELV Power Supply Source,
rated 10-30V DC, max. 40A)
Power consumption
max. 1300 mA @ 24 V
IP protection class
IP 20
Area of application
Dry environments
Operating temperature
0 – 50 °C
Storage temperature
-20 – 60 °C
Humidity
0 – 95% (non condensing)
Dimensions (max.)
48 mm x 137 mm x 140 mm (W x D x H)
Weight (max.)
650 g
Housing (material)
Metal with plastic front
Mounting
DIN rail mounting (based on DIN EN 50022)
I/Os and standard interfaces
Digital inputs
4 pcs. digital inputs (10-30V) (fuse-protected), (Low 0-3,2 V DC, High 8-30 V
DC)
Digital outputs
2 pcs. digital outputs (200mA max. / output), 200 mA @ 12 V DC / 100 mA @ 24
V DC
LAN interfaces
4 pcs. 10/100 Mbit/s full and half duplex operation, autodetection patch cable /
crossover cable
USB interface
USB Host 2.0
VPN
VPN protocol
IPsec/PPTP/OpenVPN, 64
tunnel
Item no.: 8810-UL, 8811-UL, 8812-UL, 8813-UL,
8814-UL, 8830-UL, 8831-UL, 8833-UL, 8834-UL,
8850-UL-EU, 8850-UL-AT&T, 8855-UL-EU,
8855-UL-AT&T
Encryption method
Blowfish, AES, DES/3DES
VPN protocol
OpenVPN, 1 tunnel
Item no.: 8815-UL, 8816-UL, 8817-UL, 8818-UL,
8819-UL, 8835-UL*, 8841-UL, 8849-UL,
8858-UL-EU, 8858-UL-AT&T, 8859-UL-EU,
8859-UL-AT&T
Encryption method
Blowfish
Encryption algorithm
MD5, SHA1
Authorization
Pre-Shared-Key, X.509
*can only be operated with mbCONNECT24, mymbCONNECT24.hosted, -.virtual, -.mini, -.midi or -.maxi
Network / Security
Firewall
1:1 NAT, IP-Filter, Port forwarding, stateful inspektion
IP-Router
NAT-IP, TCP/IP routing, IP forwarding
Services
DHCP server, DHCP client, DNS server, NTP client, PPP server, DynDNS
Time synchronization
NTP server
