Status – VPN OpenVPN

Label

Description

Connections in-

bound/outbound

Shows both the incoming and outgoing VPN connections of the router.

An active connection is indicated by a green dot.

The name, local address and peer address are displayed here. You can manually connect

or disconnect the connection here also. However it is not recommended to use

these buttons unless requested to do so by a member of the support

team.
