Page 168 of 237

Version: 5.1.6 – June 4

, 2019

Protocol settings

Label

Description

Protocol op-

tions

You select the coding algorithms, hash total algorithms, etc. used during the various phases

on this tab.

PFS: This setting is only supported for the router-router connection. PFS must be disabled if

you want to set up a client-router connection.
