6. What is included in the package

First, check that the following parts are in the product package:

All devices

mbNET router

Quick Start Guide

Straight-through Ethernet cable

Router variants with analog modem

Router variants with GSM modem (3G, 4G)

RJ11 plug

RJ10 to TAE adapter

GSM antenna (SMA male)

Router variants with WiFi modem

Wifi / Bluetooth antenna (2.5 m cable length) (SMA female)

Should any of these parts are missing or damaged, please contact the following address:

MB connect line GmbH

Winnettener Str. 6

91550 Dinkelsbühl

GERMANY

Tel.: +49 (0)9851/282529-0

Fax: +49 (0)9851/282529-99

Please keep the original box and the original packaging in case you need to send the device for repair

at a later date.
