Page 22 of 237
Version: 5.1.6 – June 4
th
, 2019
9. First time operation
Router installation
Mounting position / minimum distances
The mbNET router is designed for mounting on DIN rails (in accord-
ance with DIN EN 50 022) and is intended for switchgear installation.
Installation and mounting must be carried out in accordance with VDE
0100 / IEC 364. The router may only be installed in vertical position as
described.
Failure to observe the minimum distances can destroy the device at
high ambient temperatures!
DIN rail mounting
Insert the router into the DIN rail. To do this, position the upper guide on the rail and then press the router
downwards against the rail until fully inserted.
