Settings for connecting two industrial routers – PPTP – server

If you wish to use other addresses,

set the "Autoconfig" option to NO and you will see the

picture on the right:

□ From the home page navigation

bar on the left, click

VPN and on the navigation bar at

the top click PPTP.

□ This will display the screen below.

If you now set the “Enable” box and save this setting, your server is live. It will then provide dial-in clients with

addresses from its local network and use its LAN address as the PPTP server address.
