Status – VPN-IPSEC

Label

Description

Connections in-

bound /

outbound

Shows both the incoming and outgoing VPN connections of the router.

An active connection is indicated by a green dot.

The connection duration and active user are displayed. After the connection is disconnected,

the active connection time is displayed. You can manually connect or disconnect the con-

nection here also.

However it is not recommended to use these buttons unless requested

to do so by a member of the support team.
