Page 215 of 237

Version: 5.1.6 – June 4

, 2018

Status – DHCP

Label

Description

DHCP Server

The IP addresses that the DHCP server assigns to connected clients are listed here.

System

loggings

Shows the IP addresses that the DHCP assigns and which IP addresses are not allowed.

Client

Information

Information about connected clients on the WAN port.

System

loggings

All events and errors relating to the DHCP server and client are logged.
