Page 169 of 237
Version: 5.1.6 – June 4
th
, 2018
L2TP Server Configuration
The L2TP server can be used for VPN-IPSec communication between the industrial router and a Win-
dows client. The only setting required here is a freely selectable local IP address. The addresses for
the clients should be from the same network (the start and end of the range are set under the IP ad-
dress field). The L2TP server then works in a similar way to a DHCP server and can automatically as-
sign the addresses from the set range to the clients dialing in.
The name or IP address to be assigned to the server during communication with the
Window client must be entered here. In the example this is 192.168.0.100
Remote IP address
Begin
Remote IP address
End
Assignment of client IP addresses.
The address range from which remote clients are assigned their IP address can be set
here. In the example this is 192.168.0.130 to 192.168.0.140
