Page 217 of 237

Version: 5.1.6 – June 4

, 2018

Status – NTP

Label

Description

Date Time (UTC)

Shows the current system time in Universal Time Coordinates (UTC).

Local Date Time

Shows the time using the time zone setting.

Systemloggings

Shows all notifications and error messages related to the service.
