Version: 5.1.6 – June 4

, 2019

Client authentication: With certificates

No network setting is needed on the client because it is sent to the client by the server.

Tab

Label

Description

Network

Settings

Do NAT for all out-

going traffic

This option was introduced for compatibility with mdex.

It replaces the sender IP address with the current Internet IP address.
