Enable RFC1006 routing
This option enables routing via RFC1006.
Station address of the routing gateway
If RFC1006 routing is enabled, you must enter the address of the routing gateway (14 – see
example below)
ADVICE:
To access a slave subscriber station in a subnetwork that is not directly connected, the mas-
ter gateway must be assigned as the PLC routing gateway station address on the router.
Example:
The PLC (master) is connected to the router (e.g. address 13) via MPI Bus (e.g. address 14)
and a subscriber station (e.g. address 5) is connected to the master PROFIBUS (e.g. ad-
dress 4). To now be able to access the subscriber with address 5 on the PROFIBUS via the
router (13) using MPI, routing needs to be enabled.
More information on installation is available via our Support Portal at www.connect-
line.com
MPI/PROFIBUS
baud rate
Select from the following options:
PG/PC Interface Settings, 3Mbit/s, 6Mbit/s and 12Mbit/s
Protocol
The protocol for communicating with the connected device: TCP
Port
Enter the port that will be used for communication.
Enable ports
through firewall
Checking this box means that you can access the Internet through the port assigned above,
without being blocked by the firewall.
Disable Service
Checkbox for activating / deactivating the function.
If this function is activated, the serial driver for communication between
mbDIALUP / VCOM-LAN / mbNET-S7 and the serial interface is not started.
