Version: 5.1.6 – June 4

, 2019

20.3.4.2.1 Key management

You can import a key or generate it yourself. All imported keys can be downloaded as a copy under “Down-

load”.

Tab

Label

Description

Static Keys

Name for this static key

Enter the name of the key to be generated here.

Choose static key file

A key previously generated on another system can be

imported here.
