State

Switch On or Switch Off

This button can be used to switch the currently selected output on and off.

The text Off or On above the button shows the current output state in the same way as the LED

icons under “current State”.

Green LED icon: Signal level 1 at output

Gray LED icon: Signal level 0 at output

1 Table of Contents3
