Mercury 200 OptiMax Jet Drive

Direct Fuel Injection
Page 3B-54 90-8M0050731 MAY 2011
2. Install the fuel/air pressure gauge kit. Relieve the fuel pressure into an appropriate container.
a - Fuel/air pressure gauge kit
b - Fuel pressure test valve
Dual Fuel/Air Pressure Gauge Kit 91‑881834A 1
NOTE: It is recommended that the expansion chamber be removed to provide improved access to the fuel rails.
3. Remove the coolant hose between the air compressor and expansion chamber.
4 0
2 0
6
0
8 0
1
0 0
1
2
0
1 4 0
1
6 0
4 0
2 0
6 0
8 0
1 0 0
1 2
0
1
4 0
1
6 0
a
b
16015
