Powerhead
Page 4A-8 90-8M0050731 MAY 2011
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft.
39 1 Screw and lockwasher (0.25‑20 x 0.625 in.)
40 1 Hose (1‑1/4 in.)
41 1 Hose (1‑1/2 in.)
42 1 Plug (0.50‑14 in.)
Tube Ref No. Description Where Used Part No.
12
Loctite Master Gasket Kit Crankcase cover and cylinder block mating surface 92-12564 2
14
2-cycle Premium Outboard
Oil
Upper end cap bearing and end cap O-ring surface 92-858021K01
33
Loctite 680 Retaining
Compound
Cylinder block stud threads 92-809833
95
2-4-C with Teflon Upper and lower end cap seal lips and O-rings 92-802859A 1
