Pump Unit
90-8M0050731 MAY 2011 Page 5A-3
Impeller Shaft Wrench 91‑832093A 1
Secures the impeller shaft when removing or installing the impeller nut.
Bearing Puller Assembly 91‑ 83165T
3610
Removes bearings, races and bearing carriers
Oil Seal Installation Tool 91‑850830
Installs the stator seal.
Slide Hammer 91‑34569A 1
Aids in the removal of various engine components. Use with puller jaws.
Bearing Cup Installer 91‑832018
Installs the bearing cup into the pinion shaft housing and drive housing cover.
Universal Puller Plate 91‑37241
Removes bearings from gears and the driveshaft.
Bearing Installer 91‑827983T
Installs the taper roller bearing onto the pinion shaft.
Bearing Installer 91‑832016T
Installs the bearings and seals into the pinion shaft housing.
Bearing Installer 91‑820552 1
Installs a ball bearing onto a large outside diameter shaft.
