Mercury 200 OptiMax Jet Drive Service Manual

Pump Unit
Page 5A-36 90-8M0050731 MAY 2011
10. Install new seals using the seal installer tool.
45283
11. Install a new bearing using the bearing installer tool.
45284
Bearing Installer 91‑832017
Seal Installer 91‑832019T
12. Install the retaining ring in the drive housing after the bearing is installed.
13. If replacing the impeller shaft gear bearing, remove using the universal puller plate.
a - Bearing
b - Plate
c - Mandrel
Universal Puller Plate 91‑37241
a
b
c
28155
