Creasing roller components
Reciprocal components
Name of product Product No. Specifications Remarks
Creasing roller, DN model SPA-0056 For corrugated fiberboard (E corrugated fiberboard) For RC-head
Creasing roller, CN model SPA-0057 For coated board For RC-head
Creasing roller, PN model SPA-0058 For pleated works RC-head
Crease plate EN SPA-0067 For corrugated fiberboard (E corrugated fiberboard) For RC-head
Name of product Product No. Type Remarks
Cutter holder 4N SPA-0053 A100503 For SPB-0013, 0044, 0045, 0046, 0047, 0008 (RC/RT)
Cutter holder 7N SPA-0054 A100504 For SPB-0048 (RC/RT/R)
Cutter holder RN SPA-0055 A100505 For SPB 0009 (for reflecting sheet) (RC/RT)
Cutter holder JN SPA-0061 A100515 For SPB-0031 (RC/RT)
Cutter holder 10N SPA-0077 A100567 For SPB-0051 (RC/RT)
Creasing roller DN SPB-0056 A100506 Thick (for E corrugated fiberboard) (RC)
Creasing roller CN SPB-0057 A100507 Medium (for coated board) (RC/R)
Creasing roller PN SPB-0058 A100508 Fine (for coated board) (RC)
Crease plate EN SPB-0067 A100545 For corrugated fiberboard (E board B board) (RC)
Crease plate AN SPB-0103 A100891 For corrugated fiberboard
(A corrugated fiberboard AB corrugated fiberboard) (RC/R)
Cutter holder 06 SPB-0099 A100887 For SPB-0064. For sponge 20 mm (RT)
Cutter holder 07 SPB-0114 A100211 For SPB-0055, 0065. Until AB corrugated fiberboard (RC)
Cutter holder 2N SPB-0113 A100210 For SPB-0043, 0044, 0045, 0046, 0047, 0008. Up to 2-mm
thick (RC/RT/R)
Titanium coated blade 45˚ SPB-0008 A100106 SPA-0053 holder use. SPA-0113 use.
Titanium coated both
blades
SPB-0009 A100128 SPA-0055 holder use
Carbide both blades SPB-0031 A100372 SPA-0061 use
High-speed steel blade 30˚ SPB-0043 A100509 SPA-0053 use. SPA-0113 use.
High-speed steel blade 45˚ SPB-0044 A100510 SPA-0053 use. SPA-0113 use.
Carbide blade 30˚ SPB-0045 A100528 SPA-0053 use. SPA-0113 use.
Carbide blade 45˚ SPB-0046 A100529 SPA-0053 use. SPA-0113 use.
Titanium-coated blade 30˚ã SPB-0047 A100530 SPA-0053 use. SPA-0113 use.
High-speed steel blade 30˚
7 mm
SPB-0048 A100531 SPA-0054 use
Carbide design blade 30˚ SPB-0051 A100561 SPA-0077 use
