Maintenance Manual Contents R.2.2 P.2
Maintenance Manual Contents
5.1.4 PARAM. DRAW
5.1.5 MEMORY CHECK
5.1.6 Key Board Test
5.1.7 LCD Test
5.1.8 Temperature Check
5.1.9 UV LEVEL Check
5.1.10 INK IC Check
5.1.11 INK TEST
5.1.12 ENCORDER Check
5.1.13 EVENT LOG
5.1.14 Message Check
5.1.15 HW Test
5.2 Other Test
5.2.1 Ink route leak confirmation procedure
6 Disassembly and Reassembly
6.1 Covers
6.1.1 Cover Layout
6.1.2 Key Panel Assy
6.1.3 “Tube_FFC Holder” Stick the
Protection tape
6.2 Ink-related Parts
6.2.1 Head Assy
6.2.2 Dumper
6.2.3 Pump Head
6.2.4 Station Assy.
6.2.5 Wipe Suction Pump Assy.
6.2.6 Cartridge Guide Assy.
6.2.7 Cartridge Coupling Assy.
6.2.8 Capping
6.2.9 Wiper unit Assy(Belt, Sensor)
6.3 Driving Parts
6.3.1 X-axis Motor Assy
6.3.2 Y-axis Motor
6.3.3 Table
6.3.4 Z-Driving Screw
6.3.5 Slider Relay Cooling Fan Assy
6.3.6 Mist Suction Fan Assy
6.3.7 Tabel Absorption Fan
6.3.8 Linear Encorder Scale
6.3.9 X Gear Box
6.3.10 Motor Coupling
6.4 PCBs
6.4.1 Power Supply PCB Assy
6.4.2 Main PCB
6.4.3 3042 Slider Relay PCB Assy
6.4.4 3042 Station 3 PCB Assy
6.4.5 Slider PCB
6.4.6 3042 Pump 3 PCB Assy
6.4.7 ID Contact PCB
6.4.8 Keyboard PCB
6.4.9 Linear Encoder PCB
6.5 Sensors
6.5.1 X origin sensor
6.5.2 Z origin sensor
6.5.3 Work area sensor
6.5.4 Cover sensor
6.5.5 Table Cover sensor
6.6 Other Electrical Parts
6.7 UV Parts
6.7.1 LED UV UNIT
6.7.2 UV Cooling Unit
6.7.3 Cooling Water Pump
6.7.4 Radiator Fan Assy.
6.8 Greasing
7 Troubleshooting
7.1 Details on Errors and Malfunctions
7.1.1 Concerning Errors and Malfunctions
7.1.2 List of Error Messages
7.1.3 List of Warning Messages
7.1.4 List of SYSTEM HALT
7.1.5 Troubles Without Messages
Displayed
7.2 Detailed Methods of Coping with the
Malfunctions
7.2.1 Cannot start for “SYSTEM HALT(1)
11c:SLDR PCB H”
7.2.2 Discharging defect cannot be
improved by cleaning.
8 Operation Flow
8.1 Basic Operation
8.1.1 Start
8.2 Print Mode
8.2.1 LOCAL / REMOTE
8.2.2 FUNCTION
8.2.3 SETUP
8.2.4 MAINTENANCE
8.2.5 MACHINE SETUP
8.3 Service Mode
8.3.1 #ADJUST
8.3.2 #TEST
8.3.3 #PARAMETER
Maintenance Manual > Maintenance Manual Contents
Model UJF-3042/FX Issued 2010.08.27 Revised 2013.07.18 F/W ver 1.80 / 1.00 Remark
2.2
Rev.
