4.6.16.2 LEDs in the module cover
The module cover can be found at the rear of the device.
⑤⑤
LED 1 LED 2 LED 3 LED 4
O No connection (HW) No power No power or no IP
address
Constant green Connection (HW) Controlled by scan-
ner
"Online," link estab-
lished
Flashing green Not congured, or
scanner not active
Packet is received or
transmitted
"Online," no link es-
tablished
Constant red Fatal error Duplicate IP address,
major error
Flashing red Minor recoverable
error
Connection timeout
Alternating red/
green
Self-test running Self-test running
