Minebea Intec X3 Process Indicator PR 5410 User Manual

— 112 ModbuS ModBus RTU
— Port See Chapter 7.17.1.
— 113 SMA SMA
— Port See Chapter 7.17.1.
— 114 EW-CoM EW-Com
— Port See Chapter 7.17.1.
— 115 xBPI xBPI
— Port See Chapter 7.17.1.
— HS Hardware status
— 120 Slot 1 EMPtY = empty or PR 5510 card type
— 121 Slot 2 EMPtY = empty or PR 5510 card type
— 122 Slot 4 EMPtY = empty or PR 1721 card type
— 123 bAt bAt oK battery status
— Pd Pendeo search
— 124 SEArCH Search for Pendeo load cells and set dead load;
see Chapter 5.5.8
— CA Filling mode, only for EasyFill
— 150 dModE Select lling mode
nE.t = Net lling (B1) or ne.t d.l. = Net decrease
(B4)
— IM Interaction mode, only for EasyFill
— 151 IModE Select interaction mode
See Chapter 8.2.2.
— PC Congure printout, only for EasyFill
— 160 nuMPrt Number of printouts
— 161 SEqnr Enter sequence number.
— 162 PrtMod Select printing mode.
LAyout = appl. layout or nICELb =
NiceLabelExpress
— 163168 LAyou 16 Congure line 16.
nEt = net weight, GroSS = gross weight,
MAtnAM = material name, nonE = no printout,
FF = formfeed, SEq = sequence number, dAtE =
date and time, SEtP = set point, tArE = tare
weight, nL = CR/LF (carriage return and line
feed)
— do Congure digital outputs, only for EasyFill
— 170172 out 13
Enter SPM addresses %MXxxx; see Chapter 13.4
— dI Congure digital inputs, only for EasyFill
— 174176 InP 13
Enter SPM address %MXxxx; see Chapter 13.4
— ou Congure digital outputs (PR 5510/12), only for
EasyFill
— 180191 out 112
Enter SPM address %MXxxx; see Chapter 13.4
— In Congure digital inputs (PR 5510/12), only for
EasyFill
— 192197 out 16
Enter SPM address %MXxxx; see Chapter 13.4
X3 Process Indicator PR 5410 7 Commissioning
Minebea Intec EN-126
