Continue for "dead load with empty scale":
Dening the span (Cd004)
Continue for "range with weights":
dEAdLo appears on the display.
22. Press OK.
LoAd (dead load with empty scale) appears on the display.
23. Press to select the "mV/V" entry if necessary.
MVolt appears on the display.
24. Press OK.
unLoAd appears on the display.
25. Empty the scale.
26. Press OK.
A weight value for the dead load appears on the display.
27. Press OK.
00000.0 kg appears on the display.
The dead load is set.
28. Press OK.
Cd 004 appears on the display.
29. Press OK.
SPAn appears on the display.
30. Press OK.
LoAd (range with weights) appears on the display.
31. Press to select the "mV/V" entry if necessary.
MVolt appears on the display.
32. Press OK.
33. Place the calibration weight on the scale.
A weight value that has not been calibrated yet appears on the display.
34. Press OK.
WEIGHt appears on the display.
35. Press OK.
7 Commissioning X3 Process Indicator PR 5410
EN-129 Minebea Intec
