Minebea Intec X3 Process Indicator PR 5410 User Manual

The more signicant part of the address* 172.024. (example) appears on the
display.
9. If DHCP "oFF" is selected: Press the cursor keys to select and set the desired numbers.
10. Once the last number is selected and set, press to set the less signicant part of
the address*.
020.128. (example) appears on the display.
11. If DHCP "oFF" is selected: Press the cursor keys to select and set the desired numbers.
12. Press OK.
nP 082 appears on the display.
13. Press OK.
SubnEt (subnet mask) appears on the display.
14. Press OK.
The more signicant part of the mask* 255.255. appears on the display.
15. Press the cursor keys to select and set the desired numbers.
16. Once the last number is selected and set, press to set the less signicant part of
the mask*.
255.255. appears on the display.
17. Press the cursor keys to select and set the desired numbers.
18. Press OK.
nP 083 appears on the display.
19. Press OK.
GtAddr (gateway) appears on the display.
20. Press OK.
The more signicant part of the address* 000.000. appears on the display.
21. Press the cursor keys to select and set the desired numbers.
22. Once the last number is selected and set, press to set the less signicant part of
the mask*.
000.000. appears on the display.
23. Press the cursor keys to select and set the desired numbers.
24. Press OK.
X3 Process Indicator PR 5410 7 Commissioning
Minebea Intec EN-140
