7.17.1.6 xBPI protocol
The following window opens:
4. Select [Protocol] and conrm.
V1 = for old communication programs
V2 = for formulation controller
V3 = for OPC
A selection window opens.
5. Conrm the desired selection.
6. Select [Baudrate] and conrm.
A selection window opens.
7. Select the desired transmission speed and conrm.
8. Select [Bits] and conrm.
A selection window opens.
9. Select the desired bit quantity and conrm.
10. Select [Slave ID] and conrm.
11. Enter the address (A–Z) and conrm.
12. Press two times to exit the menu and save.
1. Select [xBPI-Port] and conrm.
A selection window opens.
2. Select the desired interface and conrm.
