Bytes 063
Name Type of data Function
Byte 1
Bit 0: MSB
Bit 0: ADC error
Bit 1: above max. + still permis-
sible range (OVL)
Bit 2: above max. (FSD)
Bit 3: below zero
Bit 4: zero ±¼ d
Bit 5: within zero set range (ZSR)
Bit 6: weight is stable
Bit 7: weight above max. (FSD)
and below overload
BOOL
Byte 2 Bit 0: read material data valid
Bit 1: change calibration
Bit 2: tare
Bit 3: reserved
Bit 4: reserved
Bit 5: power failure (power fail)
Bit 6: within menu [Set-
up]/[Conguration]
Bit 7: lling mode
BOOL Bit 0:
The material data is available.
Bit 1:
Calibrate weighing point.
Bit 2:
Set tare of the instrument.
Bit 5:
After a power failure the bit is set and can
be reset by bit 0 in byte 2.
Bit 6:
Filling is not possible within the menu
items.
Bit 7:
status-controlled: 0 = ll, 1 = empty
Byte 3 Bit 0: error in the application
Bit 1: lling is active
Bit 2: system ready
Bit 3: lling stopped
Bit 4: coarse ow
Bit 5: ne ow
Bit 6: calming time
Bit 7: tolerance alarm
BOOL Bit 0:
Error bit is set if any action has failed.
We recommend evaluating the error bit
(Appl_Error) and the detailed error code in
byte 63 after each action.
Bit 1:
The lling phase is active.
Bit 2:
The system is ready for lling.
Bit 3:
Filling was stopped.
Bit 4:
System is lling: coarse ow bit is set.
Bit 5:
System is lling: ne ow bit is set.
Bit 6:
The bit is set according to the set calming
time.
Bit 7:
alarm if tolerance is above/below set point
Byte 47
Gross DINT/REAL Weight
Byte 811
Net DINT/REAL Weight
Byte 1215
Tare DINT/REAL Weight
X3 Process Indicator PR 5410 12 Fieldbus interface
Minebea Intec EN-310
