Description Data
External supply
+5 V+24 V DC
Voltage drop Approx. 0.9 V
Output current Max. 50 mA
Enable input 5 V/24 V congurable via switch S101
@ 5 V active-high >3.1 V; active-low <1.5 V
@ 24 V active-high >16 V; active-low <10 V
Protection against incorrect polarity
Potential isolation No
Cable type Screened twisted pair (e.g. LifYCY 2x2x0.20)
Cable length max. 50 m screened
Accessories D-SUB male connector, 26-pin
Incl. shielded housings
