Mobius AIRO Mobile CT System - Setting the 2 D Start Position

MI-42-0001 Rev. 19 107
SCANNING: Typical Scan Sequence: New Scan
6.8.13 Setting the 2D Start Position
How to Set the 2D
Start Position
Figure 78
Step
Using the arrows
a move Ring to start position.
NOTE: Minimum Scout Scan length is 7.9cm (3.11 in.).
Keep continuous visual contact with the system and the patient when system
components are in motion.
Options Action
To select the start position Touch
s Next.
To redefine the end position Touch
d Back and reposition the Ring.
To turn on the laser to aid
positioning
Touch Laser.
Icon indicates that lasers are
On f
NOTE: Touch again to turn Laser off.
ds
f
a
