274 MI-42-0001 Rev. 19
DETACHABLE PENDANT: Technical Description for Detachable Pendants
13.4 Technical Description for Detachable Pendants
13.4.1 Detachable Pendant Specifications
AIRO Detachable
Pendant
Specifications
NOTE: For specifications of the hardwired Pendant hardware, see section 9.3.6 Pendant
Specifications.
Figure 186
Category Specification
Physical Dimensions
35 cm (13.8 in.) x 3 cm (1.1 in.) x 29 cm (11.5 in.)
Weight 1.7 kg (3.7 lbs.)
Touchscreen
Capacitive Touch Display
13.5 cm (5.3 in.) x 21.6 cm (8.5 in.)
Storage None
Input Voltage 24 Vdc
Power Consumption 5 W
