MI-42-0001 Rev. 19 45
TRANSPORT MODE: Transportation
3.3.3 Starting from Parked Position
How to Confirm
AIRO is Ready for
Transport
Figure 22
Steps
1. Ensure that the system is powered on. See section 3.3.1 Turn On Power.
2. Log in with a user-level or higher password. See section 3.3.2 Logging In.
3. From the Choose Mode screen on the Pendant, select Transport. See Figure 37 on
page 70.
4. Unplug and secure power, network, and Pendant cables.
The images below show the required coiling directions on systems with and without
installed cable Strain Reliefs.
Power Cable:
Coil counter-clockwise
from top-left hook.
To Next Page
