Mobius AIRO Mobile CT System - Raising the System for Transport; Transportation

MI-42-0001 Rev. 19 53
TRANSPORT MODE: Transportation
3.3.7 Raising the System for Transport
How to Raise the
System
When the system has been in Scan mode or parked with the base lowered, the system prompts
users to raise the base up before it enables Transport mode.
Figure 27
3.3.8 Transportation
Diagram
Figure 28
NOTE: Leave the Pendant in the holster when transporting the system.
Step
Press and hold Up
a until the camera window appears.
The system is ready for transport.
NOTE: System will not transport (camera window will not appear) if power cord is plugged in.
a
a
!
s
