Mobius AIRO Mobile CT System - Moving the Ring in Scan Mode; Translating the Ring (Z-Axis)

MI-42-0001 Rev. 19 75
SCANNING: Moving the Ring in Scan Mode
6.4 Moving the Ring in Scan Mode
6.4.1 Translating the Ring (Z-axis)
How to Translate
the Ring on the
Base
When in Scan mode, use the direction keys on the Pendant Display to control Ring translation.
Figure 41
Step Action
To move the Ring back and forth
Press and hold the left
a or right s directional button
on the Pendant Display.
a
s
