MI-42-0001 Rev. 19 51
TRANSPORT MODE: Transportation
3.3.6 Rotating and Latching the Ring in Transport or Scan Position
How to Rotate and
Latch the Ring
The Ring has a Transport position in line with the base and column, and two Scan positions at 90°
angles to the base. While the Transport position locks in the middle of the base, the two Scan
positions configure AIRO to scan in opposite directions along the Z-axis of the base.
To scan toward the base-column (STB) along the Z-axis, rotate the Ring so that it both is at 90°
across the base and has the Mobius AIRO logo away from the column.
To scan away from the base-column (SAB) along the Z-axis, rotate the Ring so that it both is at 90°
across the base and has the Mobius AIRO logo toward the column.
Rotate the Ring slowly and carefully. Rotating the Ring quickly can damage the anchor
point of the Ring latch.
If resistance occurs during Ring rotation, do not force Ring into place. Contact
Technical Service immediately.
3. From the Choose Mode screen, select
Transport
.
The screen shows instructions for locking the Ring into Transport position a.
4. Following the on-screen instructions, lift the latch
s to release the lock and rotate the Ring
until it latches into the transport orientation parallel, and in line with the base. See
Figure 25.
See cautions about rotating the Ring in section
3.3.6 Rotating and Latching the Ring in Transport or Scan Position.
5. Move, or translate, the Ring toward the middle of the base’s Z-axis until it latches.
Move the Ring slowly and carefully. Moving the Ring quickly can damage the anchor
points in the Ring and Transport latches.
6. Unplug power and network cables.
7. Raise the system to transport. See section 3.3.7 Raising the System for Transport.
Steps
