DETACHABLE PENDANT: Maintenance with Detachable Pendants
13.3 Maintenance with Detachable Pendants
13.3.1 Connecting Detachable Pendants
How to Connect
Detachable
Pendants
NOTE: The following procedure applies only to AIRO systems that feature Detachable Pendants.
No similar functionality is available for systems with hardwired Pendants.
If the system features a Detachable Pendant, it uses a barrel-ring connector for connecting and
disconnecting the pendant cable to the system at the connector below the Ring latch.See Figure 25.
Figure 181
Figure 182
