74 MI-42-0001 Rev. 19
SCANNING: Before Scanning
j
Ethernet connection to hospital network (green when connected)
k
Ethernet connection to navigation system (green when connected)
l
System temperature:
Cyan - tube is cold, a warm-up scan must be performed
Green - 0 to 33% of tube heat capacity is used
Yellow - 33% to 66% of tube heat capacity is used
Orange - 66% to 100% of tube heat capacity is used
Red - Over 100% of tube heat capacity is used. Call service; do not attempt to use the
system.
NOTE: System temperature icon indicates status of x-ray tube.
Task Bar icons
