264 MI-42-0001 Rev. 19
TROUBLESHOOTING: Transport Failure
Raise the System
How to Transport
Steps
1.
Thread the screw from the emergency kit
a into the center hole s ball end down. (See
Figure 179 on page 263.)
2. Using the Allen wrench, tighten the screw clockwise until AIRO begins to lift.
3. Turn until the machine lifts about 1/2” off the ground (approximately nine turns).
Steps
1. Rotate the Gimbal into the locked position.
See cautions about rotating the Ring in section
3.3.6 Rotating and Latching the Ring in Transport or Scan Position.
2. Lock the Gimbal in transport position.
3. Follow the steps in section 12.5.2 Base is Lifted but System Will Not Move to disengage the
Main Drive with the release lever.
4. Position a person at each end of the system.
5. At the same time:
• Person on the end of the system opposite the Pendant/power cord:
Place hands on the Ring’s support bezel for the camera panel and push system to move
it.
Do not push on the camera or camera panel.
• Person on the Pendant end of the system:
Help steer or guide AIRO to storage or service location.
NOTE: If necessary, ask for assistance in guiding system to a safe storage or service
location.
6. When the system is in a location adequate for storage, use the Allen wrench to remove the
emergency kit bolt from the center hole s.
7. Place the emergency kit back onto the retention magnets.
8. Reinstall the panel removed to access the emergency kit.
9. Return the Ring to the upright position, and reinstall the Tilt Stops.
10. Label the system as not for use and contact technical support.
