Table 7-47 Drive Manager Screen Components
Screen Components Description
Communication The communication phases (states) are shown on the right hand side in
text form (e.g. Communication phase 4).
• 1, 2 or 3: Startup phase or parameter set transfer
• 4: Cyclical mode OK
Torque
Torque of the drive in percent of the maximum torque.
The value is shown both graphically and numerically:
• Green = Normal range
• Yellow = Warning range
• Red = Critical range
The threshold values for the changing colors are dened in the drive
conguration.
Amplier
Temperature
Temperature of the drive's performance component.
The value is shown both graphically and numerically:
• Green = Normal range
• Yellow = Warning range
• Red = Critical range
The threshold values for the changing colors are dened in the drive
conguration.
Motor Temperature
Temperature of the motor.
The value is shown both graphically and numerically:
• Green = Normal range
• Yellow = Warning range
• Red = Critical range
The threshold values for the changing colors are dened in the drive
conguration.
Position
Current position of the drive.
The value is shown both graphically and numerically.
Velocity Revolution velocity of the drive (unit: rpm).
The value is shown both graphically and numerically.
Start Reference
Button
Starts and / or stops the referencing of the drive.
The current status of referencing is shown in a text line to the right of this
button.
Status Display The status display of the drive is to the right of the button Start
referencing.
The states are shown in text form, e.g. Referenced.
Drive Monitor Screen - continued
