5-68
9. Remove two stopper rings [12] and one Stopper DR [13].
10. Remove two bearings [14].
11. Remove the ROLLER EXIT DECARL [15].
[
14
]
[
13
]
[
14
]
[
15
]
[
12
]
[
12
]
12. Remove two Stopper DR [16].
13. Remove one bearing [17].
14. Remove the ROLLER SPONGE DECARL [18].
[
16
]
[
16
]
[
17
]
[
18
]
