5-99
Printer registration mode (MFX-3595)
This mode adjusts the print registration for each paper source.
1. Press <Mode>, <*>, <4>, <3>.
2. Select the paper source you want to adjust, and press [Enter].
3. Adjust the printer registration:
• Upper and lower edge adjustment is effective for all attached cassetts.
• Left and right edge adjustment is effective for each respective casette.
• Press [<] and [>] or the numeric keys, and enter the adjustment range.
When you set “+12.3” for Vertical registration, the printing image moves 12.3 mm downward. If you
set “–12.3”, the printing image moves 12.3 mm upward.
When you set “+12.3” for Horizontal registration, the printing image moves 12.3 mm rightward. If you
set “”–12.3”, the printing image moves 12.3 mm leftward. You can adjust between ”–12.7 mm” and
“+12.7 mm”.
4. Press [Enter].
Printer registration mode (MFX-3535)
This mode adjusts the print registration for each paper source.
1. Press <Mode>, <*>, <4>, <3>.
2. Select the direction to adjust, and press [Enter].
When you have selected vertical, skip to step 4.
3. Select the paper source you want to adjust, and press [Enter].
4. Adjust the printer registration:
• Press [+] or [-] at the head of the figures, and switch the adjustment direction between + or -.
• Press [+] or [-] at the end of the figures, and enter the adjustment range.
When you set “+12.3” for Vertical registration, the printing image moves 12.3 mm downward. If you
set “–12.3”, the printing image moves 12.3 mm upward.
When you set “+12.3” for Horizontal registration, the printing image moves 12.3 mm rightward. If you
set “”–12.3”, the printing image moves 12.3 mm leftward. You can adjust between ”–12.7 mm” and
“+12.7 mm”.
5. Press [Enter].
