8 Spectrum Analysis Mode
Narda SRM-3006 111
Specifying the number of peaks to be displayed
Spectrum • Evaluation • Peak Table • Number of Peaks
A maximum of 50 peaks can be displayed.
1. Press the Number of Peaks softkey.
2. Use the rotary control to highlight the desired number and then press the
OK key.
Selecting the result types
Spectrum • Evaluation • Peak Table • Select Result Type
The Select Result Type softkey is used to select the result type to be
displayed in the first column after the Service column. You can only select
from the result types that were highlighted under Spectrum • Result Type.
The selected result type is shown relative to the actual value if the relative
display mode is selected.
1. Press the Select Result Type softkey.
2. Use the rotary control to select the desired result type and press the OK
key.
Selecting absolute or relative display mode
Spectrum • Evaluation • Peak Table • Results:
The measured values are shown relative to the selected result type in
relative display mode.
⇒ Press the Results softkey:
–For absolute values: The softkey label must show Relative.
–For relative values: The softkey label must show Absolute.
Setting a threshold
Spectrum • Evaluation • Peak Table • Thrsh:
When a threshold is activated, only the peaks that are above the selected
threshold will be shown in the table.
1. Press the Thrsh softkey until the label shows On (toggle function).
2. Press the Set Thrsh softkey and use the rotary control to select a
threshold value.
3. Press the OK key.
