13 Measurement Data Memory
162 SRM-3006 Narda
To store measured values by conditional control:
1. Select the desired operating mode and then press the MENU key to
open the Main menu.
2. Press the Memory softkey, then press the Conditional Storing softkey
and set the parameters:
3. Press the Start Now softkey.
ª Automatic storage is activated.
The screen displays the view of the operating mode previously
selected. The info line shows Conditional Storing and the number of
records still to be recorded.
To stop storing values:
⇒ Storing stops automatically when the Max. Number of Records is
reached. To stop storing values before this, press the Stop softkey.
ª The operating mode is again displayed normally. You can view the
stored measurement values from the Memory menu (see Viewing
data sets on page 159).
Figure 38: Conditional Storing parameters
Condition Explanation Possible settings
Threshold Threshold above which
storage of values begins
–
Conditional Storing
Options
Number of values to be
stored
• First Value Over Threshold:
only the first value exceeding the
threshold
• All Values Over Threshold:
all the values exceeding the threshold
Max Number of
Records
• As many as possible
• 2, 3, 5, 10, 20, 30, 50, 100, 200, 300,
500
Result Type Result type viewed • Peak
• Maximum Peak
