Native Instruments MASCHINE MK3 User Manual

Selecting Type and Mode tags on your controller (here for Instrument presets).
▪ When browsing Projects, Groups, Sounds or Samples, Knob 5–7 allow you to select Type
tags in the three hierarchical levels.
▪ When browsing Instrument or Effect presets (as in the picture above), Knob 5 and 6 allow
you to select a Type and a Sub-Type, respectively; Knob 7 allows you to select a Mode.
3.2.7 List and Tag Overlays in the Browser
When browsing your Library from the controller, the touch-sensitive Knobs 1–8 provide you
with handy browsing aids.
For general information on how to use the Browse mode of your controller to browse the
MASCHINE Library, please refer to section 3.2 “Searching and Loading Files from the
Library” in the MASCHINE Manual.
List Overlays for Product Category, Bank, and Sub-Bank
As you select a product category, bank or sub-bank via Knobs 1, 3, and 4 under the left dis-
play, respectively), the corresponding list overlay appears above. These overlays are similar to
those for selectors described in section ↑2.3.5, List Overlay for Selectors. In each list, the se-
lected item is highlighted.
Browser
Searching and Loading Files from the Library
MASCHINE - Manual - 134

Native Instruments MASCHINE MK3 Specifications

General

Encoders	8 touch-sensitive knobs
Audio Interface	24-bit / 96 kHz
MIDI I/O	1 x MIDI In, 1 x MIDI Out
USB	USB 2.0
Pads	16 x Multi-color Pads, Velocity-Sensitive, Aftertouch
Display	2 full-color screens
Outputs	1/4" TRS Line Outputs, Stereo Headphone Output
Software	Maschine Software
Power Supply	USB bus-powered
Dimensions	320 x 301 x 41 mm
Weight	2.2 kg
System Requirements	Intel Core i5, 4 GB RAM
Inputs	1 x 1/4" TRS Mic Input, 2 x 1/4" TRS Line Inputs
