Native Instruments MASCHINE MK3 User Manual

For more information on the Edit and Slice pages, please refer to section ↑16.3, Editing
a Sample and ↑16.4, Slicing a Sample, respectively.
Sample Map Menu
The Sample Map menu contains additional editing facilities.
► Right-click ([Ctrl]-click on macOS) a Zone to open the Sample Map menu.
The commands in the Sample Map menu will affect all selected Zones. The menu provides fol-
lowing commands:
Command Description
Delete Removes the selected Zone(s) from the Sample Map.
Map as Drum Kit Reduces the selected Zones to one note over the full velocity range
and puts the Zones next to each other upwards from the middle C
(C3). The actual note assigned to each Zone depends on the Zone
position in the Zone List: The topmost Zone will be mapped to
middle C (C3), the Zone underneath to C#3, etc.
16.5.5 Editing Zones in the Sample View
{Commented by Christian Schulz, 09.09.2016 15:03:21: This needs a rework as it is really
shit}
The Sample view is visible when the Sample View button (showing a little waveform icon at the
right of the Zone tab) is enabled.
Enable the Sample View button to see the Sample view.
The Sample view contains following elements:
Sampling and Sample Mapping
Mapping Samples to Zones
MASCHINE - Manual - 871

Native Instruments MASCHINE MK3 Specifications

General

Encoders	8 touch-sensitive knobs
Audio Interface	24-bit / 96 kHz
MIDI I/O	1 x MIDI In, 1 x MIDI Out
USB	USB 2.0
Pads	16 x Multi-color Pads, Velocity-Sensitive, Aftertouch
Display	2 full-color screens
Outputs	1/4" TRS Line Outputs, Stereo Headphone Output
Software	Maschine Software
Power Supply	USB bus-powered
Dimensions	320 x 301 x 41 mm
Weight	2.2 kg
System Requirements	Intel Core i5, 4 GB RAM
Inputs	1 x 1/4" TRS Mic Input, 2 x 1/4" TRS Line Inputs
