Native Instruments MASCHINE MK3 User Manual

▪ Additionally this Pattern is loaded in the Pattern Editor, ready to be modified.
For further information regarding the Pattern mode, please refer to section ↑10.7, Man-
aging Patterns.
Removing a Pattern from a Scene on the Controller
Removing a Pattern is also done in Pattern mode:
► To remove the Pattern for the selected Group from the selected Scene, press PATTERN +
Button 2 (REMOVE).
→ The Pattern is removed from the Scene:
▪ The corresponding Pattern will not be played by that Scene anymore.
▪ The Pattern itself is left untouched.
▪ If the Pattern was the longest one in the Scene, the Scene is automatically reduced to the
next longest Pattern.
15.2.4 Selecting Scenes
You can select the desired Scene in the Ideas view.
Selecting a Scene in the Ideas View
To select a Scene in the Ideas view, do the following:
► Select the desired Scene by clicking its name at the top of the Ideas View:
Working with the Arranger
Using Ideas View
MASCHINE - Manual - 764

Native Instruments MASCHINE MK3 Specifications

General

Encoders	8 touch-sensitive knobs
Audio Interface	24-bit / 96 kHz
MIDI I/O	1 x MIDI In, 1 x MIDI Out
USB	USB 2.0
Pads	16 x Multi-color Pads, Velocity-Sensitive, Aftertouch
Display	2 full-color screens
Outputs	1/4" TRS Line Outputs, Stereo Headphone Output
Software	Maschine Software
Power Supply	USB bus-powered
Dimensions	320 x 301 x 41 mm
Weight	2.2 kg
System Requirements	Intel Core i5, 4 GB RAM
Inputs	1 x 1/4" TRS Mic Input, 2 x 1/4" TRS Line Inputs
