Native Instruments MASCHINE MK3 User Manual

6. Adjust the level for that auxiliary output via the little knob at the right of the menu.
This is equivalent to setting the Level parameter described above.
7. Set the pre/post state of the auxiliary output by clicking the Post (or Pre) label right under
the menu.
This is equivalent to setting the Order parameter described above.
11.1.4 Configuring the Master and Cue Outputs of MASCHINE
All channels routed to the Master are mixed together and processed by the Plug-ins loaded in
the Master, if any. The result is then sent to the Master output (that is, MASCHINE’s main out-
put).
Besides, all channels currently routed to the Cue bus for pre-listening are mixed together and
sent to the Cue output.
For more information on how to use the Cue bus, see section ↑12.2.6, Using the Cue
Bus.
You can choose to which outputs (on your audio interface or in your host) both Master and Cue
outputs should be sent, and adjust their respective levels and panoramic positions. This is
done on the Audio page of the Output properties for the Master.
Audio Routing, Remote Control, and Macro Controls
Audio Routing in MASCHINE
MASCHINE - Manual - 548

Native Instruments MASCHINE MK3 Specifications

General

Encoders	8 touch-sensitive knobs
Audio Interface	24-bit / 96 kHz
MIDI I/O	1 x MIDI In, 1 x MIDI Out
USB	USB 2.0
Pads	16 x Multi-color Pads, Velocity-Sensitive, Aftertouch
Display	2 full-color screens
Outputs	1/4" TRS Line Outputs, Stereo Headphone Output
Software	Maschine Software
Power Supply	USB bus-powered
Dimensions	320 x 301 x 41 mm
Weight	2.2 kg
System Requirements	Intel Core i5, 4 GB RAM
Inputs	1 x 1/4" TRS Mic Input, 2 x 1/4" TRS Line Inputs
