Native Instruments MASCHINE MK3 User Manual

6. Press SHIFT + Button 7 (BYPASS) above the right display to bypass the selected Plug-in
slot.
→ The Plug-in is bypassed and does not affect the sound anymore. In the left display the
Plug-in icon and name are grayed out. When you hold SHIFT, Button 7 is fully lit and the
BYPASS label on the right display is highlighted to indicate that this Plug-in slot is now
bypassed:
Use the same method to unmute the effect:
► To unmute the effect, press SHIFT + the lit Button 7 (BYPASS).
In most cases the first Plug-in slot contains an Instrument Plug-in (e.g., a Sampler). Be
careful: bypassing the slot will mute the whole Sound!
6.1.6 Using Side-Chain
Some Plug-ins provide side-chaining. This allows you to control their influence on the audio via
another audio signal sent to their secondary, side-chain input. This extra routing feature is de-
scribed in details in section ↑13.1.3, Using the Side-Chain Input.
6.1.7 Moving Plug-ins
MASCHINE allows you to move Plug-ins across the Plug-in List and across Sounds and Groups.
Working with Plug-ins
Plug-in Overview
MASCHINE - Manual - 293

Native Instruments MASCHINE MK3 Specifications

General

Encoders	8 touch-sensitive knobs
Audio Interface	24-bit / 96 kHz
MIDI I/O	1 x MIDI In, 1 x MIDI Out
USB	USB 2.0
Pads	16 x Multi-color Pads, Velocity-Sensitive, Aftertouch
Display	2 full-color screens
Outputs	1/4" TRS Line Outputs, Stereo Headphone Output
Software	Maschine Software
Power Supply	USB bus-powered
Dimensions	320 x 301 x 41 mm
Weight	2.2 kg
System Requirements	Intel Core i5, 4 GB RAM
Inputs	1 x 1/4" TRS Mic Input, 2 x 1/4" TRS Line Inputs
