The process of using Gate mode is as follows; load an audio loop onto a Sound, select Gate
mode from the control panel of the Audio plug-in and then add MIDI events in the Pattern in
the regions where you want to chop and pitch your audio, or press play on your controller and
use the pads to pitch the audio. For more information on recording and editing events, refer to
chapter ↑10, Working with Patterns.
To zoom into a Pattern, double-click on the vertical scroll bar to the right of the Pattern
Editor.
Using the Audio Plug-in
Using Gate Mode
MASCHINE - Manual - 334

Native Instruments MASCHINE MK3 Specifications

General

Encoders	8 touch-sensitive knobs
Audio Interface	24-bit / 96 kHz
MIDI I/O	1 x MIDI In, 1 x MIDI Out
USB	USB 2.0
Pads	16 x Multi-color Pads, Velocity-Sensitive, Aftertouch
Display	2 full-color screens
Outputs	1/4" TRS Line Outputs, Stereo Headphone Output
Software	Maschine Software
Power Supply	USB bus-powered
Dimensions	320 x 301 x 41 mm
Weight	2.2 kg
System Requirements	Intel Core i5, 4 GB RAM
Inputs	1 x 1/4" TRS Mic Input, 2 x 1/4" TRS Line Inputs
