Parameter Description
INPUT Section
Source Selects the audio signal you want to use as side-chain signal to
control the Plug-in. Available options are None (side-chain
disabled, default setting), the outputs of all (other) Sounds , and
the outputs of all (other) Groups.
In the menu these outputs are labeled as follows:
For Groups: [Group name] (e.g., Drums)
For Sounds: [Group name]: [Sound name] (e.g., Drums: Kick)
In the selector display these outputs are labeled as follows:
For Groups: [Group name] (e.g., Drums)
For Sounds: [Group letter+number]:S[Sound number] (e.g., A1:S4 for
the Sound 4 of Group A1)
Gain
Adjusts the input level of the side-chain signal fed into the Plug-in.
FILTER Section
Filter Activates a filter on the side-chain input. This filter can be useful to
select only a specific frequency range of the side-chain signal to
control the Plug-in.
Center Freq Adjusts the center frequency of the filter.
Width Adjusts the bandwidth of the filter.
On your controller the outputs available in the SOURCE parameter are labeled as in the
display of the Source selector described above.
For more information on how to use the side-chain input, please refer to section
↑13.1.3, Using the Side-Chain Input.
Effect Reference
Dynamics
MASCHINE - Manual - 667

Native Instruments MASCHINE MK3 Specifications

General

Encoders	8 touch-sensitive knobs
Audio Interface	24-bit / 96 kHz
MIDI I/O	1 x MIDI In, 1 x MIDI Out
USB	USB 2.0
Pads	16 x Multi-color Pads, Velocity-Sensitive, Aftertouch
Display	2 full-color screens
Outputs	1/4" TRS Line Outputs, Stereo Headphone Output
Software	Maschine Software
Power Supply	USB bus-powered
Dimensions	320 x 301 x 41 mm
Weight	2.2 kg
System Requirements	Intel Core i5, 4 GB RAM
Inputs	1 x 1/4" TRS Mic Input, 2 x 1/4" TRS Line Inputs
