Native Instruments MASCHINE MK3 User Manual

Adjust the slicing settings via Knob 1–4.
Any change to these settings will directly affect the number and position of the Slice markers
shown in the waveform on the displays.
Selecting and Pre-Listening the Slices with the Pads
At any time, the proposed Slices are also available on your pads: The fully lit pad indicates the
selected Slice, while the dim lit pads indicate the other Slices.
► Press any fully or dim lit pad to play back the corresponding Slice on the Cue bus (see
section ↑12.2.6, Using the Cue Bus for more information).
For more information on the Cue channel, please refer to section ↑12.2.6, Using the
Cue Bus.
If there are more than 16 Slices, you can select which set of 16 Slices should be triggered by
your pads:
► If there are more than 16 Slices, press SHIFT + Button 7 or 8 to switch your pads to the
previous/next 16 Slices, respectively.
Note that we haven’t applied any slicing yet: For now your pads only allow you to prelis-
ten how the proposed would sound after you apply the slicing. Applying the slicing will
be described in section ↑16.4.5, Applying the Slicing.
Slicing Parameters
Following parameters are available:
Sampling and Sample Mapping
Slicing a Sample
MASCHINE - Manual - 842

Native Instruments MASCHINE MK3 Specifications

General

Encoders	8 touch-sensitive knobs
Audio Interface	24-bit / 96 kHz
MIDI I/O	1 x MIDI In, 1 x MIDI Out
USB	USB 2.0
Pads	16 x Multi-color Pads, Velocity-Sensitive, Aftertouch
Display	2 full-color screens
Outputs	1/4" TRS Line Outputs, Stereo Headphone Output
Software	Maschine Software
Power Supply	USB bus-powered
Dimensions	320 x 301 x 41 mm
Weight	2.2 kg
System Requirements	Intel Core i5, 4 GB RAM
Inputs	1 x 1/4" TRS Mic Input, 2 x 1/4" TRS Line Inputs
