Native Instruments MASCHINE MK3 User Manual

Parameter Description
START (Knob 1) Adjusts the playback’s start point in the Sample of the focused Zone.
END (Knob 2) Adjusts the playback’s end point in the Sample of the focused Zone.
► Hold SHIFT when turning the Knobs to adjust the parameters in finer increments.
In the waveform on the right display, the regions outside the play range are grayed out.
Page 2 – LOOP Parameters
The parameters in the LOOP page allow you to define and adjust a portion that will play in loop
while the note is held.
The ZONE page on the controller, page 2 of 5: LOOP parameters.
Parameter Description
ACTIVE (Knob 1) Enable this to define a loop in the Sample of the focused Zone.
When the play position reaches the loop, the playback is looped as
long as the note is held. This can be useful to loop either a whole
Sample or part of it, e.g., to simulate a longer tone. Note: this
technique requires that you set the Sampler’s TYPE selector to AHD
or ADSR in the PITCH / GATE section (Parameter page 2, see
↑6.2.2, Page 2: Pitch / Envelope).
START (Knob 2) Adjusts the start point of the loop.
Sampling and Sample Mapping
Mapping Samples to Zones
MASCHINE - Manual - 878

Native Instruments MASCHINE MK3 Specifications

General

Encoders	8 touch-sensitive knobs
Audio Interface	24-bit / 96 kHz
MIDI I/O	1 x MIDI In, 1 x MIDI Out
USB	USB 2.0
Pads	16 x Multi-color Pads, Velocity-Sensitive, Aftertouch
Display	2 full-color screens
Outputs	1/4" TRS Line Outputs, Stereo Headphone Output
Software	Maschine Software
Power Supply	USB bus-powered
Dimensions	320 x 301 x 41 mm
Weight	2.2 kg
System Requirements	Intel Core i5, 4 GB RAM
Inputs	1 x 1/4" TRS Mic Input, 2 x 1/4" TRS Line Inputs
